Lamella Mat is comprised of mineral fibre batons rotated 90°, faced with Bright Class ‘O’ reinforced aluminium foil. The product is an excellent thermal insulator and vapour barrier for air and ventilation ducts, curved bodies, and other equipment.
Specification
| Thickness (mm) | Length (mm) | Width (mm) |
|---|---|---|
| 25 | 8000 | 1200 |
| 30 | 8000 | 1200 |
| 40 | 6000 | 1200 |
| 50 | 5000 | 1200 |
| 60 | 4000 | 1200 |
| 80 | 3000 | 1200 |
| 100 | 2000 | 1200 |
Available in the following densities: 32kg/m³ (supplied in 1 meter), 45kg/m³, 60kg/m³, 80kg/m³.
